Hey Tim,
Did a search, using my new friend Gemini, but centred it on Black Magic Fusion.
I have no idea as to whether this will work:
To export multi-layer EXR files in Blackmagic Fusion, you need to combine your different passes (such as Beauty, Z-Depth, Ambient Occlusion, or Motion Vectors) into a single image stream using Channel Booleans or Merge nodes before routing them into a single Saver node.
Here is how to set up and export a multi-layer EXR file.
<b role=”heading” data-sfc-cp=”” jsaction=”” jscontroller=”gjwZNd#ZxCkTb” data-sfc-root=”ep” jsuid=”jGM9nf_4″>1. Combine Your Passes
Fusion passes standard RGBA channels by default. To add extra layers (like Depth or Vectors) into the same stream:
- Add a Channel Boolean node: Branch your main Beauty pass into a Channel Boolean node (<code jsaction=”” jscontroller=”jM7ape#mDCHfd” data-sfc-root=”ep” jsuid=”jGM9nf_a”>Ctrl + Spacebar > type <code jsaction=”” jscontroller=”jM7ape#mDCHfd” data-sfc-root=”ep” jsuid=”jGM9nf_b”>Channel Boolean).
- Connect the Extra Pass: Connect your secondary pass (e.g., Z-Depth) into the secondary input (green foreground pip) of the Channel Boolean.
- Map the Channels: In the Channel Boolean inspector, go to the Aux Channels tab. Change the target channel (e.g., Z Buffer) from <em jsaction=”” jscontroller=”ABoAEd#jBqpid” data-sfc-root=”ep” jsuid=”jGM9nf_i”>Operation: Copy and select the corresponding channel from your secondary input.
<b role=”heading” data-sfc-cp=”” jsaction=”” jscontroller=”gjwZNd#ZxCkTb” data-sfc-root=”ep” jsuid=”jGM9nf_j”>2. Add and Configure the Saver Node
- Connect the Saver: Connect the output of your final Channel Boolean node to a Saver node.
- Set Format to OpenEXR: In the Saver properties, click Browse, name your file with a sequence extension (e.g., <code jsaction=”” jscontroller=”jM7ape#mDCHfd” data-sfc-root=”ep” jsuid=”jGM9nf_r”>Multilayer_Render.0000.exr), and ensure the format is set to OpenEXR.
- Enable Extra Channels: In the Saver inspector panel, look for the Channels or Format settings. Ensure that checkboxes for auxiliary channels (like Z, Coverage, or custom channels) are enabled so they write into the final EXR payload.
<b role=”heading” data-sfc-cp=”” jsaction=”” jscontroller=”gjwZNd#ZxCkTb” data-sfc-root=”ep” jsuid=”jGM9nf_z”>3. Choose the Right Compression
Multi-layer EXR files can get very large. In the Saver node’s format options, select an appropriate compression method:
- ZIP (Scanline or Block): Excellent for general 2D compositing and widely compatible across software like Nuke or After Effects.
- PIZ: Great lossless compression for noisy or grainy 3D renders, though it can be slightly slower to decode.
<b role=”heading” data-sfc-cp=”” jsaction=”” jscontroller=”gjwZNd#ZxCkTb” data-sfc-root=”ep” jsuid=”jGM9nf_16″>4. Render the Sequence
- Go to the top menu bar.
- Select Fusion > Render All Savers (or press <code jsaction=”” jscontroller=”jM7ape#mDCHfd” data-sfc-root=”ep” jsuid=”jGM9nf_1c”>F7).
- Set your frame range and click Start Render.
Gemini got the information from these two YouTube videos:
https://youtu.be/aiJB6YwtkWk?si=Ibc5VKvGf1pMsbQi
https://www.youtube.com/live/WWykNgpHAfc?si=zyByyjS30KaAFIxF
Hope this helps?
Please do come back and share your experiences, as Blender is making its way into the professional world of media production. And it is nice to know how it works in a Davinci workflow.
Atb
Mads
