Saturn V2 with Rings and Shadows

Makin’ Planets! Saturn (with rings and shadows)

In this video, I’m revisiting my earlier tutorial showing how to add rings to a planet when using Video Copilot’s Orb plugin. I show how to make the rings using Polar Coordinates, then use an Alpha Invert Matte along with a simple expression to cut the rings out. I then add fake shadows using adjustment layers to have the planet cast a shadow on the rings and the rings cast shadows on the planet.

Finally, I show how to recreate the planet and rings in Cinema4D Lite (included in the Adobe After Effects CC licence)

Some contents or functionalities here are not available due to your cookie preferences!

This happens because the functionality/content marked as “Google Youtube” uses cookies that you choosed to keep disabled. In order to view this content or use this functionality, please enable cookies: click here to open your cookie preferences.

Original tutorial: https://youtu.be/DFlnj8B4yeo
Project Download: https://bit.ly/39ycYhX
Textures from: https://www.solarsystemscope.com/

Expressions used:
Dan Ebberts’ LookAts

X Rotation:

1
2
delta = toWorld(anchorPoint) – thisComp.layer(“Sun”).toWorld([0,0,0]);
radiansToDegrees(Math.atan2(delta[1],delta[2]))*-1
Y Rotation:

1
2
delta = toWorld(anchorPoint) – thisComp.layer(“Sun”).toWorld([0,0,0]);
radiansToDegrees(Math.atan2(delta[0],delta[2]))*-1+180
Variation for the shadow on the planet:

1
2
3
4
5
6
7
Angle = comp(“Saturn”).layer(“Shadow Pointer”).transform.xRotation;
if (Angle < 0) {
Angle=Angle*-1;
}
X = linear(Angle, 90, 180, 50, 100);
Y = linear(Angle, 90, 180, -25, -50);
[X,Y]

Graham Quince<br>Halifax, UK
Graham Quince
Halifax, UK

I mainly work in compositing, 3D modelling and programming, but nothing at a broadcast level. I’ve used the Adobe suite for 20 years.
